WIWA EFFECTIVE
- Optimum spraying results due to low pressure fluctuations
- Robust unit with few wearing parts and simple assembly and disassembly
- Minimalist design: all operating elements positioned on the front and thus quickly accessible
Description
The WIWA EFFECTIVE for trade and industry.
Minimalist design for even easier handling. All operating elements are positioned on the front side and thus quickly accessible. Hose holder at the rear of the spraying unit for better storage of the hoses. Optimum spraying result due to low pressure fluctuations. Robust unit with few wearing parts and easy assembly and disassembly. All parts in contact with the material are made of stainless steel.
Technical Data
| Version | RS |
| Pressure ratio | 33:1 |
| Output per cycle | 27 ccm |
| Max. output | 4.2 l/min |
| Max. operating pressure | 264 bar |
| Piston diameter air motor | 85 mm |
| Piston stroke air motor | 75 mm |
| Order numbers | |
| D/DAS | 0666441 |
| F/DAS | 0659810 |
| F/GZ | 0660089 |
| F/ASL | 0660090 |
| W/ASL | 0666442 |
B - On container, D - on tripod, F - on chassis, G - on rack, GZ - On Rack with feed funnel, W - on wall mount,
ASL - suction tube, DAS - Direct suction
Fields Of Application
- Joineries
- Furniture industry
- Painting and varnishing companies
- Machine and vehicle construction
The WIWA EFFECTIVE for trade and industry.
Minimalist design for even easier handling. All operating elements are positioned on the front side and thus quickly accessible. Hose holder at the rear of the spraying unit for better storage of the hoses. Optimum spraying result due to low pressure fluctuations. Robust unit with few wearing parts and easy assembly and disassembly. All parts in contact with the material are made of stainless steel.
| Version | RS |
| Pressure ratio | 33:1 |
| Output per cycle | 27 ccm |
| Max. output | 4.2 l/min |
| Max. operating pressure | 264 bar |
| Piston diameter air motor | 85 mm |
| Piston stroke air motor | 75 mm |
| Order numbers | |
| D/DAS | 0666441 |
| F/DAS | 0659810 |
| F/GZ | 0660089 |
| F/ASL | 0660090 |
| W/ASL | 0666442 |
B - On container, D - on tripod, F - on chassis, G - on rack, GZ - On Rack with feed funnel, W - on wall mount,
ASL - suction tube, DAS - Direct suction
Fields Of Application
- Joineries
- Furniture industry
- Painting and varnishing companies
- Machine and vehicle construction
