WIWA 225/250/400 Airless automatic gun
- Fast closing
- For fully and semi-automatic coating systems
- Suitable for waterborne and solventborne paints
Description
Robust, fast closing automatic spray gun.
For even more precise and faster closing, a connection option for a pneumatic closing device is provided. The automatic guns are equipped with a material return connection and can be used both with and without circulation.
Suitable products
Technical Data
| Model | WIWA Airless automatic gun 225 |
| Order number | 0646339 |
| Description | with connection thread 1/4" valve needle 4 mm |
| Max. operating pressure | 225 bar |
| Model | WIWA Airless automatic gun 250 |
| Order number | 0630876 |
| Description | with connection thread 1/4" valve needle 4 mm |
| Max. operating pressure | 250 bar |
| Model | WIWA Airless automatic gun 400 |
| Order number | 0642193 |
| Description | mit Anschlussgewinde 1/4“ Ventilnadel 3 mm |
| Max. operating pressure | 400 bar |
| Model | WIWA Airless automatic gun 400 |
| Order number | 0643134 |
| Description | with connection thread M16x1.5 Valve needle 3 mm |
| Max. operating pressure | 400 bar |
| Model | WIWA Airless automatic gun 400 |
| Order number | 0646154 |
| Description | with connection thread 3/8" valve needle 3 mm |
| Max. operating pressure | 400 bar |
| Model | WIWA Automatic valve |
| Order number | 0632419 |
| Description | Automatic valve 4 mm with return -RS- |
| Max. operating pressure | 250 bar |
B - On container, D - on tripod, F - on chassis, G - on rack, GZ - On Rack with feed funnel, W - on wall mount,
ASL - suction tube, DAS - Direct suction
Robust, fast closing automatic spray gun.
For even more precise and faster closing, a connection option for a pneumatic closing device is provided. The automatic guns are equipped with a material return connection and can be used both with and without circulation.
Suitable products
| Model | WIWA Airless automatic gun 225 |
| Order number | 0646339 |
| Description | with connection thread 1/4" valve needle 4 mm |
| Max. operating pressure | 225 bar |
| Model | WIWA Airless automatic gun 250 |
| Order number | 0630876 |
| Description | with connection thread 1/4" valve needle 4 mm |
| Max. operating pressure | 250 bar |
| Model | WIWA Airless automatic gun 400 |
| Order number | 0642193 |
| Description | mit Anschlussgewinde 1/4“ Ventilnadel 3 mm |
| Max. operating pressure | 400 bar |
| Model | WIWA Airless automatic gun 400 |
| Order number | 0643134 |
| Description | with connection thread M16x1.5 Valve needle 3 mm |
| Max. operating pressure | 400 bar |
| Model | WIWA Airless automatic gun 400 |
| Order number | 0646154 |
| Description | with connection thread 3/8" valve needle 3 mm |
| Max. operating pressure | 400 bar |
| Model | WIWA Automatic valve |
| Order number | 0632419 |
| Description | Automatic valve 4 mm with return -RS- |
| Max. operating pressure | 250 bar |
B - On container, D - on tripod, F - on chassis, G - on rack, GZ - On Rack with feed funnel, W - on wall mount,
ASL - suction tube, DAS - Direct suction
